• 3-pin XLR female to 5-pin XLR male cable adapter

• Suitable for DMX supported lighting fixtures

• Neutrik connectors

This is a DAP cable adapter to link a 3-pin female to a 5-pin male DMX cable. This DMX adapter can help in solving interconnection problems in lighting applications.

Specifications

Electrical Specifications and Connections

Impedance         110 Ω

DMX Connector In                XLR 5P

DMX Connector Out                 XLR 3P

Brand Connector 1                Neutrik

Pins              3

Cable Length                 0.25 m

Mechanical Specifications

Length (mm)                250 mm (9.843″)

Weight               0.084 kg (0.185 lb)

IP Rating                IP20 (indoor use only)

Colour              Black

Product Properties

1st Shield               Aluminium foil

Conductors                3
