• 100 W LED beam moving head with controllable LED ring

• 11 colours + white and rainbow effect

• 14 gobos with gobo shake

• Two rotating prisms, 16- and 24-facet

• Frost and motorised focus

The Showtec Shark - The Meg - Beam One is a compact but powerful 100 watt LED moving head with a very narrow beam angle of 1.6 degrees and lots of impressive effects, including a controllable LED ring effect. It has a colour wheel with 11 colours plus open and a rainbow effect. Two individually controllable and indexed rotating prisms with 16 and 24 facets can be alternated, and the gobo wheel with gobo shake has 14 gobos + open. The motorised focus allows for razor sharp (gobo) images, while the frost filter provides a smoothed out beam dispersion. The LED ring can be controlled separately and produces selectable graphic patterns in selectable colours. The Shark - The Meg - Beam One can be controlled through DMX and Master/Slave, and has several built-in programs for stand-alone operation.

Specifications

Source
Light Source Type   LED
Light Source Quantity   1
Light Source Power    100 W
LED Colour Type    CW
Illuminance @ 2 m     822769 lx
Illuminance @ 3 m    365675 lx
Illuminance @ 5 m    131643 lx
Luminous Flux (Total)    6056 lm
CRI    761

Optical
Beam Angle Max. (Circular)    1.6 °
Frost    Yes
Focus    Motorised

Control and Programming
Control Mode    Built-in Program, DMX, Master Slave
DMX Channels    15, 22, 30
Protocols    DMX
Display     TFT
Fan mode    Yes

Dynamic Effects
Dimmer    0-100 %
Strobe    0-20 Hz
Prism 1    16-facte Circulair
Prism 2    24-facet Linear
Prism Overlay    No
Prism Index & Rotate    Yes
Colour System    Colour Wheel
Dichroic Colour Wheel 1   11 + Open
Gobo System    Metal
Gobo Wheel 1    14 + Open

Movement
Pan    540 °
Tilt   270 °
Pan/Tilt Resolution   16-bit

Electrical Specifications and Connections
Power Supply    100-240 V AC 50/60 Hz
Power Consumption    175 W
Fuse   4 A
Power Connector In   Power Pro Blue
Power Connector Out   Power Pro Grey
DMX Connector    XLR 3P In/Out
DMX Connector In    XLR 3P
DMX Connector Out   XLR 3P

Mechanical Specifications
Length (mm)    165 mm (6.496″)
Width (mm)    275 mm (10.827″)
Height (mm)    430 mm (16.929″)
Weight    10.85 kg (23.92 lb)
IP Rating    IP20 (indoor use only)
Housing    Metal, PVC
Colour    Black

Product Properties
Cooling    Axial fan

Rigging
Mounting Options   Quick-Lock
Safety Attachment    Yes
Safety Eyes   1

Thermal Specifications
Maximum Ambient Temperature    40 °C (104 °F)

Included Items
Included Cables    Power Pro Cable
Included Rigging   Quick-Lock Bracket
