• 60 W Spot Moving Head with 15° fixed beam angle

• 5 gobos + open & 7 colours + white

• 3-facet prism & motorised focus

• Infrared remote included

• Compact, one-clamp-mount design

The Showtec Shark Spot One is a compact 60 watt LED Spot Moving Head suitable for indoor venues. Its 5 gobos with motorised focus and 7 dichroic colour filters with rainbow-flow effect, create nice, razor-sharp optical effects. Each function and effect, like its 3-facet prism, dimmer, strobe and gobo flow and -shake functions can be controlled via DMX. Additionally, the Shark Spot One includes an infrared remote for wireless point-and-shoot control. With a single press on the button, you can activate Auto Run and Sound-controlled built-in programs, as well as other available features and effects.

Specifications

Source

Light Source Type    LED

Light Source Quantity   1

Light Source Power    60 W

LED Colour Type    CW

Illuminance @ 5 m    1784 lx

Luminous Flux (Total)    800 lm

CCT    8000 K

Optical

Beam Angle Max. (Circular)    15 °

Focus    Motorised

Control and Programming

Control Mode    Auto, DMX, Master Slave, Remote, Sound

DMX Channels    8, 14

Protocols    DMX

Display    OLED

Dynamic Effects

Dimmer    0-100 %

Strobe    0-20 Hz

Prism 1    3-facet Circulair

Prism Index & Rotate    No

Colour System     Colour Wheel

Colour Wheel Index & Rotate    Yes

Dichroic Colour Wheel 1   7 + Open

Gobo System    Glass + Metal

Gobo Wheel Index & Rotate    Yes

Gobo Wheel 1   5 + Open

Movement

Pan    540 °

Tilt   200 °

Electrical Specifications and Connections

Power Supply   100-240 V AC 50/60 Hz

Power Consumption   110 W

Power Connector In   IEC

DMX Connector   XLR 3P In/Out

DMX Connector In    XLR 3P

DMX Connector Out    XLR 3P

Mechanical Specifications

Length (mm)    214 mm (8.425″)

Width (mm)    144 mm (5.669″)

Height (mm)    335 mm (13.189″)

Weight    4.6 kg (10.141 lb)

IP Rating    IP20 (indoor use only)

Housing   Metal, Plastic

Colour    Black

Product Properties

Cooling    Axial fan

Rigging

Mounting Options    Bracket

Safety Attachment   Yes

Safety Eyes    1

Thermal Specifications

Maximum Ambient Temperature    40 °C (104 °F)

Included Items

Included Cables    IEC cable

Included Rigging   Bracket

Included Remotes   IR Remote
